电气特点:
触点额定电流 (A) = 8
Contact - Limiting Continuous Current (A) = 8
Contact - Limiting Making Current (A) = 8
Contact - Limiting Breaking Current (A) = 8
Insulation - Initial Dielectric Between Open Contacts (V rms) = 1500
介电强度 － 线圈接触体 (V rms) = 4000
Contact - Switching Voltage Max. (VAC) = 400
Contact - Limiting Short-Time Current (A) = 8
线圈电压 (VDC) = 12
线圈电阻 (Ω) = 180
额定线圈功率 (mW) = 801
Coil - Rated Power Class = 800mW to 1000mW Class
Insulation - Initial Dielectric Between Adjacent Contacts (V rms) = 2500
Insulation - Clearance Class = >8mm Class
Insulation - Creepage Class = >8mm Class
尺寸:
长度 (mm [in]) = 40.00 [1.575]
宽度 (mm [in]) = 13.00 [0.512]
高度 (mm [in]) = 16.50 [0.650]
Insulation - Clearance Between Contact and Coil (mm [in]) = 10 [0.394]
Insulation - Creepage Between Contact and Coil (mm [in]) = 10 [0.394]
主体特性:
安装方式 = PCB
重量 (g [oz]) = 30.00 [1.058]
|
触点特性:
端子类型 = PCB-THT
Contact Material = AgSnO
Contact - Number of Poles = 4
Contact - Special Features = Force Guided Contacts
配置特性:
触点组合形式 = 2 Form A (NO) + 2 Form B (NC)
线圈励磁系统 = Monostable, DC
行业标准:
符合RoHS/ELV标准 = 符合RoHS标准, 符合ELV 标准
无铅焊接制程 = 波峰焊最高可达240°C, 波峰焊最高可达260°C
RoHS/ELV 符合记录 = 改为符合 RoHS 指令
Approved/Registered Standards = CQC, TUEV, cULus, VDE
环境:
Environmental - Category of Protection = RTIII
Environmental - Ambient Temperature, Max. (°C [°F]) = 70 [158]
Environmental - Ambient Temperature Class = 50°C to 70°C Class
包装特性:
包装方式 = 塑料管包装
其他:
产品系列 = SR4 D/M
品牌 = Schrack
|
|
|
